Description


The Ecovan ER02 is designed for commercial vans, delivering the optimal balance of durability, longevity, and fuel efficiency.

  • Advance LRR compounds improve fuel efficiency
  • Three longitudinal grooves offer better water-channeling efficiency and shorter braking distance
  • Wave-shaped tread design ensures even wear and tire enhances longevity

Detailed Information


Type and Size
Tire Model
Federal Ecovan ER02
Car Type
Light Truck / SUV
Season
Summer
Rim Diameter
14 / 15 / 16 "
Width
165 / 175 / 185 / 195 / 205 / 215 / 225 / 235 mm
Aspect Ratio
60 / 65 / 70 / 75 %
Construction
Radial
Special Features
Runflat
No
Mud and Snow
No
Extra Load
No
Speed and Load
Speed Index
Q (max 100 mph) ... T (max 118 mph)
Load Index (max load for a tire)


Federal Ecovan ER02 Sizes & Specifications


Rim Model Size Index Features sidewall styling tread depth (mm) max load (kg) tread width (mm) tread width (inch) overall diameter (mm) rim width utqg max inflation pressure approved rim width max load (lbs) tread depth (inch) overall diameter (inch) load range section width (mm) section width (inch) tire weight
R14 165/60 R14 97/95Q 165/60 R14 97/95Q BW 12.0 124.0 4.9 328 4.5 65.0 4-5.5 9.6 12.9 C 173 6.8 10.2
R14 165/70 R14 95/94R 165/70 R14 95/94R BW 12.0 128.0 5.0 588 5.0 65.0 5-6 9.6 23.1 C 170 6.7 9.7
R14 175/65 R14 90/88T 175/65 R14 90/88T BW 12.0 136.0 5.4 585 5.0 54.0 5-6 9.9 23.0 C 177 7.0 9.6
R14 205/75 R14 109/107Q 205/75 R14 109/107Q BW 12.0 149.0 5.9 664 5.5 69.0 5-7 9.5 26.1 C 205 8.1 11.9
R15 195/70 R15 108/106R 195/70 R15 108/106R BW 8.0 151.0 5.9 656 6.0 80.0 5-6.5 6.3 25.8 C 203 8.0 14.1
R15 205/65 R15 108/106T 205/65 R15 108/106T BW 12.0 161.0 6.3 649 6.0 65.0 5.5-7.5 9.9 25.5 C 212 8.3 12.7
R15 205/70 R15 106/104S 205/70 R15 106/104S BW 12.0 157.0 6.2 669 6.0 65.0 5-7 9.5 26.4 C 210 8.3 12.8
R15 215/65 R15 110/108T 215/65 R15 110/108T BW 12.0 170.0 6.7 623 6.5 65.0 6-7.5 9.8 24.5 C 220 8.7 13.3
R15 215/70 R15 109/107R 215/70 R15 109/107R BW 12.0 166.0 6.5 684 6.5 65.0 5.5-7 9.5 26.9 C 219 8.6 14.1
R15 225/70 R15 117/115R 225/70 R15 117/115R BW 12.0 171.0 6.7 700 6.5 80.0 5.5-7 9.6 27.6 C 233 9.2 14.9
R16 175/75 R16 101/99R 175/75 R16 101/99R BW 12.0 130.0 5.1 669 5.0 69.0 4.5-6 9.6 26.3 C 177 7.0 11.4
R16 185/75 R16 104/102R 185/75 R16 104/102R BW 12.0 135.0 5.3 684 5.0 69.0 4.5-6 9.6 26.9 C 186 7.3 12.3
R16 195/75 R16 110/108R 195/75 R16 110/108R BW 12.0 144.0 5.7 703 5.5 76.0 5-6 9.6 27.7 C 197 7.8 13.1
R16 205/65 R16 107/105T 205/65 R16 107/105T BW 12.0 161.0 6.3 673 6.0 69.0 5.5-7.5 9.9 26.5 C 209 8.2 13.3
R16 205/75 R16 113/111R 205/75 R16 113/111R BW 12.0 149.0 5.9 716 5.5 76.0 5-7 9.6 28.2 C 196 7.7 15.3
R16 215/60 R16 108/106R 215/60 R16 108/106R BW 13.0 172.0 6.8 665 6.5 69.0 6-7.5 10.7 26.2 C 219 8.6 13.2
R16 215/65 R16 109/107T 215/65 R16 109/107T BW 12.0 170.0 6.7 690 6.5 69.0 6-7.5 9.8 27.1 C 220 8.7 13.7
R16 215/75 R16 116/114R 215/75 R16 116/114R BW 12.0 159.0 6.3 730 6.0 76.0 5.5-7 9.6 28.7 C 214 8.4 16.6
R16 225/65 R16 112/110R 225/65 R16 112/110R BW 12.0 176.0 6.9 700 6.5 69.0 6-7 9.8 27.6 C 226 8.9 14.5
R16 225/75 R16 121/120R 225/75 R16 121/120R BW 12.0 164.0 6.5 747 6.0 83.0 6-7.5 9.6 29.4 C 220 8.7 17.9
R16 235/65 R16 118/116R 235/65 R16 118/116R BW 12.0 185.0 7.3 711 7.0 76.0 6.5-8.5 9.8 28.0 C 237 9.3 16.9
