Description


  • Zigzag center rib design increases grip performance on straight way.
  • Four broad circumferential groove design with 35% void ratio enhances drainage efficiency and maneuverability on wet road condition.
  • Broad circumferential groove design (outside groove wall angle>inside groove wall angle) drains water more easily, and even prevents slipping.
  • 3-Dimension arc groove design between blocks helps increasing stiffness between blocks, and also disturbs air flow in grooves.
  • Applying “groove in groove” concept on circumferential grooves disperses stress on tire surface, and prevents irregular wear and noise produced by the friction between air flow and groove wall.
  • Separating circumferential grooves and radial grooves decreases rolling noise.

Detailed Information


Type and Size
Tire Model
Sonar Conqueror SX-9
Car Type
Passenger
Season
All Season
Rim Diameter
15 / 16 / 17 / 18 / 19 / 20 / 22 / 24 "
Width
205 / 215 / 225 / 235 / 245 / 255 / 265 / 275 / 285 / 295 / 305 / 315 mm
Aspect Ratio
35 / 40 / 45 / 50 / 55 / 60 / 65 / 70 %
Construction
Radial
Special Features
Runflat
No
Mud and Snow
No
Extra Load
Optional
Speed and Load
Speed Index
H (max 130 mph) ... Y (max 186 mph)
Load Index (max load for a tire)


Sonar Conqueror SX-9 Sizes & Specifications


Rim Model Size Index Features load range measured rim width section width (mm) overall diameter (mm)
R15 205/70 R15 96H 205/70 R15 96H 6.0 209.0 669.0
R15 255/60 R15 102H 255/60 R15 102H 7.5 260.0 687.0
R15 275/60 R15 107H 275/60 R15 107H 8.0 279.0 711.0
R16 215/65 R16 102H XL 215/65 R16 102H XL XL 6.5 221.0 686.0
R16 235/65 R16 107V XL 235/65 R16 107V XL XL 7.0 240.0 712.0
R16 265/70 R16 112S 265/70 R16 112S 8.0 272.0 778.0
R16 275/70 R16 114H 275/70 R16 114H 8.0 279.0 792.0
R17 225/60 R17 99H 225/60 R17 99H 6.5 228.0 702.0
R17 225/65 R17 102V 225/65 R17 102V 6.5 228.0 724.0
R17 235/55 R17 103V XL 235/55 R17 103V XL XL 7.5 245.0 690.0
R17 235/65 R17 108V XL 235/65 R17 108V XL XL 7.0 240.0 738.0
R17 245/65 R17 111H XL 245/65 R17 111H XL XL 7.0 248.0 750.0
R17 255/60 R17 110V XL 255/60 R17 110V XL XL 7.5 260.0 738.0
R17 255/65 R17 110H 255/65 R17 110H 7.5 260.0 764.0
R17 265/65 R17 112H 265/65 R17 112H 8.0 272.0 776.0
R17 265/70 R17 115H 265/70 R17 115H 8.0 272.0 804.0
R17 275/65 R17 115H 275/65 R17 115H 8.0 279.0 790.0
R17 285/65 R17 116H 285/65 R17 116H 8.5 292.0 802.0
R18 215/55 R18 99V XL 215/55 R18 99V XL XL 7.0 226.0 693.0
R18 235/55 R18 104V XL 235/55 R18 104V XL XL 7.5 245.0 715.0
R18 235/60 R18 107V XL 235/60 R18 107V XL XL 7.0 240.0 739.0
R18 245/60 R18 105H 245/60 R18 105H 7.0 248.0 751.0
R18 255/55 R18 109V XL 255/55 R18 109V XL XL 8.0 265.0 737.0
R18 255/55 R18 109Y XL 255/55 R18 109Y XL XL 8.0 265.0 737.0
R18 255/70 R18 113H 255/70 R18 113H 7.5 260.0 815.0
R18 265/60 R18 110V 265/60 R18 110V 8.0 272.0 775.0
R18 265/65 R18 114H 265/65 R18 114H 8.0 272.0 801.0
R19 225/55 R19 99Y 225/55 R19 99Y 7.0 233.0 731.0
R19 235/55 R19 101W 235/55 R19 101W 7.5 245.0 741.0
R19 245/55 R19 107H XL 245/55 R19 107H XL XL 7.5 253.0 753.0
R19 255/50 R19 107V XL 255/50 R19 107V XL XL 8.0 265.0 739.0
R19 255/55 R19 111V XL 255/55 R19 111V XL XL 8.0 265.0 763.0
R19 255/60 R19 109H 255/60 R19 109H 7.5 260.0 789.0
R19 275/55 R19 111V 275/55 R19 111V 8.5 284.0 785.0
R19 285/45 R19 111V XL 285/45 R19 111V XL XL 9.5 285.0 739.0
R20 245/50 R20 102V 245/50 R20 102V 7.5 253.0 754.0
R20 265/50 R20 111V XL 265/50 R20 111V XL XL 8.5 277.0 774.0
R20 275/40 R20 106V XL 275/40 R20 106V XL XL 9.5 278.0 728.0
R20 275/40 R20 106W XL 275/40 R20 106W XL XL 9.5 278.0 728.0
R20 275/45 R20 110V XL 275/45 R20 110V XL XL 9.0 273.0 756.0
R20 275/55 R20 117H XL 275/55 R20 117H XL XL 8.5 284.0 810.0
R20 285/50 R20 116V XL 285/50 R20 116V XL XL 9.0 297.0 794.0
R20 295/45 R20 114H XL 295/45 R20 114H XL XL 10.0 296.0 774.0
R20 305/50 R20 120H XL 305/50 R20 120H XL XL 9.5 316.0 814.0
R20 315/35 R20 110W XL 315/35 R20 110W XL XL 11.0 320.0 728.0
R22 265/35 R22 102V XL 265/35 R22 102V XL XL 9.5 271.0 745.0
R22 305/40 R22 114V XL 305/40 R22 114V XL XL 11.0 313.0 803.0
R22 305/45 R22 118V XL 305/45 R22 118V XL XL 10.0 303.0 833.0
R24 305/35 R24 112V XL 305/35 R24 112V XL XL 11.0 313.0 824.0
